Motor diesel Styer 6126ZLD4 300HP

\ n El motor diésel Styer 6126ZLD4 300HP se utiliza para grupos electrógenos. Es una potencia estable para grupos electrógenos de 180KW y 200KW. \ n \ n \ n \ n \ n Especificación y datos para el motor diésel Styer 6126ZLD4 300HP \ n

TECHNICAL DATA OF DIESEL ENGINE
DIESEL ENGINE MODEL		6126ZLD4
Engine Characters		four stroke , water cooling , in line , direct injection
Rated Power(HP)		300HP
Aspiration		Turbocharged and aftercooler
No of Cylinders		6
Rated speed (rpm)		1500
Arrange of Cyls(inline/vee)		in line
Displacement of Piston (L)		9.726
Fuel Consumption (g/kw.h)	At rated output	≤ 210
	At 75% load	≤ 222.6
	At 50% load	≤ 238.7
Bore(mm) X Stroke(mm)		126*130
Exhaust temperature (℃)		≤600
Oil temperature(℃)		≤95
Cooling water temperature(℃)		75-95
Oil pressure (Mpa) at rated output		0.30 - 0.60
Steady adjust speed rate %		≤5.0
Oil Consumption (g/kw.h)		≤1.63
Exhaust smoke BSU		≤3.80
Mix idling steady speed r/min		≤600
Oil pressure (Mpa) at idling		≥0.10
Firing order		1-5-3-6-2-4
Starting mode		electric starting
